1. Testing and Verifying the Battery Pack

Once your battery pack is assembled, it's essential to test and verify its functionality before use. Here's how to do it safely:

• Visual Inspection: Carefully examine all connections to ensure there are no loose wires or obvious issues.

• Voltage Check: Use a multimeter to measure the voltage at the main output terminals. This should match the expected voltage based on your configuration (e.g., 12V for a single 4S pack, 48V for a 4S4P setup).

• Individual Module Check: If possible, measure the voltage across each module to ensure they all contribute equally to the total pack voltage.

• BMS Function Test: If your pack includes a Battery Management System (BMS), test its functionality by:

• Attempting to charge the pack slightly above its maximum voltage (the BMS should prevent this).
• Attempting to discharge the pack slightly below its minimum voltage (the BMS should cut off the discharge).



2. Understanding Load Capabilities

Now that your battery pack is assembled and tested, it's crucial to understand its capabilities, especially in terms of the current it can safely deliver.

2.1. Amperage Limits

The maximum current your battery pack can safely deliver depends on several factors:

• Individual Module Limits: Each 4S module typically has a current limit, such as 5 amps for continuous discharge.
• Number of Parallel Connections: The total current capability increases with the number of modules connected in parallel. For example, if each module can deliver 5 amps, a pack with 16 modules (4 stacks of 4) could theoretically deliver 80 amps (16 x 5A).
• PCB Board Limits: The larger PCB board itself has current limitations based on its trace width and copper thickness. Our example board is designed for up to 100 amps.
• Connector Limits: The output connectors also have current ratings. In our example, each of the two output connectors can handle 50 amps continuously, allowing for a total of 100 amps.
• BMS Limits: If you're using a BMS, it will have its own current limit which may be the bottleneck in some cases.

Always use the lowest of these limits as your pack's maximum continuous current rating.

2.2. Expanding Capacity

One of the great advantages of this modular system is the ability to easily expand your pack's capacity:

• Adding Modules: You can increase the capacity by adding more modules to your existing stacks, as long as your PCB board has available slots.
• Parallel Packs: For even larger capacity increases, you can connect multiple complete packs in parallel. This allows you to exceed the limitations of a single PCB board.

Considerations when expanding:

• Ensure all modules and packs being connected have the same voltage.
• Use appropriately sized cables and connectors for higher currents.
• Consider upgrading your BMS if you're significantly increasing the pack size.



3. 48V Version of the PCB Board

While we've primarily discussed the 12V version of the PCB board, there's also a 48V version available. This higher voltage version operates on the same principles but with some key differences:

• Series Connection: Unlike the 12V board, which connects modules in parallel, the 48V board connects four 12V module stacks in series to achieve the higher voltage.
• Voltage Output: As the name suggests, this board provides a 48V output, making it suitable for applications that require higher voltages.
• Current Ratings: The 48V board typically has different current ratings compared to the 12V version:
• Discharge current: Often rated for 60 amps.
• Charge current: Usually around 30 amps.
• Module Configuration: You'll still use the same 4S modules, but they'll be arranged differently on the board to achieve the series connection.
• Applications: This higher voltage makes it suitable for electric vehicles, solar energy systems, and industrial equipment.
• Safety Considerations: Working with 48V systems requires additional safety precautions due to the higher voltage.

When choosing between the 12V and 48V versions, consider your specific application needs, the equipment you'll be powering, and your comfort level with higher voltage systems.

4. Conclusion and Resources

Building your own lithium-ion phosphate battery packs can be an exciting and rewarding project. It offers you the flexibility to create custom power solutions tailored to your specific needs, whether for portable power, renewable energy storage, or electric vehicle applications.

Throughout this guide, we've covered the basics of 4S lithium-ion phosphate modules, methods for building battery packs, the advantages of using a larger PCB board, step-by-step assembly instructions, important safety considerations, testing procedures, and an understanding of load capabilities. We've also touched on the 48V version of the PCB board for those needing higher voltage solutions.

Remember, while DIY battery building can be a fun and educational experience, it's crucial to prioritize safety at all times. Always follow proper procedures, use appropriate safety gear, and if you're unsure about any aspect of the process, don't hesitate to seek advice from experienced professionals.

For those interested in pursuing this project, you can find the PCB boards and modules discussed in this guide at jack35.com. They offer a range of products and resources for DIY battery builders.

As you embark on your battery-building journey, keep learning, stay safe, and enjoy the process of creating your own custom power solutions!
